Additional information
| Weight | 8,719 kg |
|---|---|
| Reference number | 81504106552, 81504106608, 81504106618, 81504106684, 81504109552, 2V5615332E, 81504106608, 2V5615332E |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 22.2604 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 421 751 0 |
| Output force 3 | 2158.17 lbf |
| Output force M | 2045.76 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 7.87 in |
| Release pressure | 79.77 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.92 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | with boot |
| Yoke | welded |
| GTIN | 7895851069749 |
| Size (mm x mm x mm) | 551 x 202 x 200 |
| UPC | 193133350750 |
| Weight (kg) | 8.719 |
| Weight (lb) | 19.22 |
| Technical specification | OE specification |
| Brand | WABCO |
