Additional information
| Weight | 9,341 kg |
|---|---|
| Reference number | 1446047, 1731942 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 34.56 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 / 123.28 psi |
| Opposite | 925 431 041 0 |
| Output force 3 | 1978.32 lbf |
| Output force M | 1708.55 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 10.24 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.83 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed: 895 802 090 4 |
| GTIN | 7895851035171 |
| Size (mm x mm x mm) | 240 x 600 x 240 |
| UPC | 193133352051 |
| Weight (kg) | 9.341 |
| Weight (lb) | 20.593 |
| Technical specification | OE specification |
| Brand | WABCO |
