Additional information
| Weight | 8,955 kg |
|---|---|
| Reference number | 1626182, 1626183, 1626184, 1626185, 1626445, 1626446, 1629514, 1629515, 8154233, 8154234, 1606887, 1606835, 1606836, 1609803, 3963095, 3963094, 8113112, 5003225, 5003226, 8113558, 5003484, 5003485, 8112624, 8112625, 8113540, 8113541, 1605737, 20438491, 20438492, 20438495, 20438496, 20466202, 20466204, 20533199, 3985507, 3986167, 8113419, 85003004 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 22.57 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 1865.91 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port thread 12 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 9.72 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Thread length | 9.72 in |
| Total lenght | 10.67 in |
| Type | 24/24 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875280743 |
| Size (mm x mm x mm) | 589 x 186 x 206 |
| UPC | 193133352143 |
| Weight (kg) | 8.955 |
| Weight (lb) | 19.74 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
