Additional information
| Weight | 8,273 kg |
|---|---|
| Reference number | 0194209118, A0194209118 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.8476 |
| Clevis pin | 0.55 in |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 491 901 0 |
| Output force 3 | 1933.36 lbf |
| Output force M | 2686.47 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.46 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.92 in |
| Type | 24/24 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | welded: 895 801 760 4 |
| GTIN | 7895851051881 |
| Size (mm x mm x mm) | 387 x 195 x 210 |
| UPC | 193133358114 |
| Weight (kg) | 8.273 |
| Weight (lb) | 18.239 |
| Stroke | 2.24 / 2.24 in |
| Brand | WABCO |
