Additional information
| Weight | 8,875 kg |
|---|---|
| Reference number | 1519177, 8143102, 8283975000, 8283975000NEU, AJZ8139, CF352160, 157898, S925-491-114-0, 505807465, 5807465, 21151105024, 306658, 79540, 10167585, 5029685, 571037108, A050010140, A05010140, A05010611, S9254911140, 070220000, 11013233, 18730, 305057, S925-491-114-0, 2089718, 051037, 51037, 4607 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 21.84 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1820.95 lbf |
| Output force M | 2023.28 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 7.87 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 24.73 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/24 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | No |
| GTIN | 04057875286363 |
| Size (mm x mm x mm) | 555 x 192 x 205 |
| UPC | 193133357247 |
| Weight (kg) | 8.875 |
| Weight (lb) | 19.57 |
| Total lenght | 10.83 in |
| Brand | WABCO |
