Additional information
| Weight | 9,17 kg |
|---|---|
| Reference number | 7073231 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.32 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 19.36 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 2742.67 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port thread 12 | M16 x 1.5 JED – 152 |
| Port threads | M16 x 1.5 |
| Push-rod length | 3.35 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Total lenght | 10.00 in |
| Type | 30/24 |
| Type of operation | Cam |
| Version | with boot |
| Yoke | Screwed: 810 612 020 4 |
| GTIN | 04057875279846 |
| Size (mm x mm x mm) | 440 x 220 x 200 |
| UPC | 193133351252 |
| Weight (kg) | 9.17 |
| Weight (lb) | 20.216 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
