Additional information
| Weight | 8,94 kg |
|---|---|
| Reference number | 0194206918, A0194206918 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 21.186 |
| Clevis pin | 0.55 in |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 492 803 0 |
| Output force 3 | 1596.14 lbf |
| Output force M | 3106.86 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 2.13 in |
| Release pressure | 59.47 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.72 in |
| Type | 27/24 IBV |
| Type of operation | Cam |
| Version | With boot |
| Yoke | welded: 895 801 770 4 |
| GTIN | 04057875287339 |
| Size (mm x mm x mm) | 230 x 230 x 400.5 |
| UPC | 193133358831 |
| Weight (kg) | 8.94 |
| Weight (lb) | 19.709 |
| Technical specification | OE specification |
| Brand | WABCO |
