Additional information
| Weight | 9,062 kg |
|---|---|
| Reference number | 1518146, A0074201218, 0064206818, 0074201218, A0074201218 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 25.451 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 116.03 / 116.03 psi |
| Output force 3 | 1955.84 lbf |
| Output force M | 1888.40 lbf |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Push-rod length | 11.42 in |
| Push-rod thread | M14 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.64 in |
| Temperature range | -40°C to +80°C |
| Thread length | 1.57 in |
| Total lenght | 10.24 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed: 895 801 140 4 |
| GTIN | 04057875276814 |
| Size (mm x mm x mm) | 653 x 192 x 203 |
| UPC | 193133347613 |
| Weight (kg) | 9.062 |
| Weight (lb) | 19.978 |
| Technical specification | OE specification |
| Brand | WABCO |
