Additional information
| Weight | 8,68 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 19.76 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 116.03 / 116.03 psi |
| Output force 3 | 1461.26 lbf |
| Output force M | 1348.85 lbf |
| Port thread 11 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 9.45 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 66.72 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Thread length | 5.31 in |
| Total lenght | 10.12 in |
| Type | 16/16 |
| Type of operation | Cam |
| Version | with boot |
| Yoke | Screwed |
| GTIN | 04057875277651 |
| Size (mm x mm x mm) | 650 x 190 x 160 |
| Weight (kg) | 8.68 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
