Additional information
| Weight | 11,206 kg |
|---|---|
| Reference number | 7128259, 0204200818, A0204200818 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 21.4544 |
| Clevis pin | 0.55 in |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 492 930 0 |
| Output force 3 | 2585.30 lbf |
| Output force M | 2585.30 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 2.13 in |
| Push-rod thread | M14 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.93 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Version | With boot |
| Yoke | Screwed: 895 801 140 4 |
| GTIN | 04057875287469 |
| Size (mm x mm x mm) | 460 x 212 x 220 |
| UPC | 193133358558 |
| Weight (kg) | 11.206 |
| Weight (lb) | 24.705 |
| Stroke | 2.56 / 2.56 in |
| Brand | WABCO |
