Additional information
| Weight | 8,1 kg |
|---|---|
| Reference number | 6954207318, A6954207318 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | 2 x M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 116.03 psi |
| Opposite | 925 324 260 0 |
| Output force 3 | 1955.84 lbf |
| Output force M | 1573.66 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.36 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.51 in |
| Type | 16/24 |
| Type of operation | Cam |
| Version | with boot |
| Yoke | welded |
| GTIN | 7895851019256 |
| UPC | 193133348511 |
| Weight (kg) | 0 |
| Weight (lb) | 0 |
| Technical specification | OE specification |
| Brand | WABCO |
