Additional information
| Weight | 11,072 kg |
|---|---|
| Reference number | 1606834, 20927128, 1605738 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 20.999 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 2427.94 lbf |
| Output force M | 2472.90 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 2.36 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 60.70 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.22 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (M 16×1.5) |
| GTIN | 04057875286820 |
| Size (mm x mm x mm) | 220 x 415 x 230 |
| UPC | 193133358046 |
| Weight (kg) | 11.072 |
| Weight (lb) | 24.4096 |
| Thread length | 2.36 in |
| Brand | WABCO |
