Additional information
| Weight | 10,95 kg |
|---|---|
| Reference number | AB9254920030, 1608006, 20927129, 1588610, 20827662 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | 5/8" – 18 UNF |
| Calculated Volume (dm³) | 19.2 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Push-rod length | 1.38 in |
| Push-rod thread | 5/8'' – 18 UNF |
| Release pressure | 71.07 psi |
| Return-spring force | 60.70 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.22 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Yoke | Without |
| GTIN | 04057875286813 |
| Size (mm x mm x mm) | 240 x 200 x 400 |
| UPC | 193133358053 |
| Weight (kg) | 10.95 |
| Weight (lb) | 24.1406 |
| Version | Without boot |
| Brand | WABCO |
