Additional information
| Weight | 9,184 kg |
|---|---|
| Reference number | 1814634, 1437485, 1437486, 1459624, 1602678 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.32 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 22.176 |
| Clevis pin | 0.55 in |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 2472.90 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 1.97 in |
| Release pressure | 71.07 psi |
| Return-spring force | 60.70 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 27/24 |
| Type of operation | Cam |
| Version | Without boot |
| Wrench size | 0.94 in |
| Yoke | Yes |
| GTIN | 04057875288107 |
| Size (mm x mm x mm) | 420 x 220 x 240 |
| UPC | 193133359425 |
| Weight (kg) | 9.184 |
| Weight (lb) | 20.247 |
| Total lenght | 10.59 in |
| Brand | WABCO |
