Additional information
| Weight | 10,337 kg |
|---|---|
| Reference number | 21149785, 21149785 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.38 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 28.5413 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 2090.72 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Push-rod length | 8.66 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 89.92 psi |
| Return-spring force | 62.95 lbf |
| Stroke | 2.56 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -45°C to +80°C |
| Total lenght | 11.30 in |
| Type | 27/24 HLF3 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | No |
| GTIN | 04057875288114 |
| Size (mm x mm x mm) | 590 x 225 x 215 |
| UPC | 193133359456 |
| Weight (kg) | 10.337 |
| Weight (lb) | 22.7892 |
| Thread length | 8.66 in |
| Brand | WABCO |
