Additional information
| Weight | 9,86 kg |
|---|---|
| Reference number | 22273773 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.7087 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 76.87 psi |
| Return-spring force | 61.15 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.71 in |
| Type | 24/30 IBV |
| Type of operation | Disc |
| Size (mm x mm x mm) | 350 x 205 x 205 |
| UPC | 193133354321 |
| Weight (kg) | 9.86 |
| Weight (lb) | 21.738 |
| GTIN | 04057875282891 |
| Brand | WABCO |
