Additional information
| Weight | 9,857 kg |
|---|---|
| Reference number | 21283631 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.05 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 481 344 0 |
| Output force M | 1933.36 lbf |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/30 |
| Type of operation | Disc |
| GTIN | 04057875283836 |
| Size (mm x mm x mm) | 350 x 215 x 200 |
| UPC | 193133355144 |
| Weight (kg) | 9.857 |
| Weight (lb) | 21.731 |
| Total lenght | 10.71 in |
| Brand | WABCO |
