Additional information
| Weight | 9,019 kg |
|---|---|
| Reference number | A05010618 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 24 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 2079.48 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Push-rod length | 7.87 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 71.07 psi |
| Return-spring force | 37.09 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.87 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | Without boot |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875286745 |
| Size (mm x mm x mm) | 200 x 600 x 200 |
| UPC | 193133357902 |
| Weight (kg) | 9.019 |
| Weight (lb) | 19.883 |
| Thread length | 7.72 in |
| Brand | WABCO |
