Additional information
| Weight | 9,8 kg |
|---|---|
| Reference number | 22080434 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 18.3897 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 1888.40 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Push-rod length | 2.28 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 89.92 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -45°C to +80°C |
| Total lenght | 11.38 in |
| Type | 24/24 HFL3 |
| Type of operation | Cam |
| Version | Without boot |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875286615 |
| Size (mm x mm x mm) | 417 x 210 x 210 |
| UPC | 193133357698 |
| Weight (kg) | 9.8 |
| Weight (lb) | 21.605 |
| Thread length | 2.28 in |
| Brand | WABCO |
