Additional information
| Weight | 9,1 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.57 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 33.05 |
| Clevis pin | 0.49 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 145.04 / 145.04 psi |
| Output force M | 3199.03 lbf |
| Port thread 11 | M22 x 1.5 |
| Push-rod length | 11.81 in |
| Push-rod thread | M14 x 1.5 |
| Release pressure | 68.17 psi |
| Return-spring force | 31.47 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 8.23 in |
| Type of operation | Cam |
| Version | With boot |
| Yoke | screwed |
| GTIN | 04057875637349 |
| Size (mm x mm x mm) | 625 x 225 x 235 |
| Weight (kg) | 9.1 |
| Weight (lb) | 20.06 |
| Type | 24/24 |
| Brand | WABCO |
