Additional information
| Weight | 8,158 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 16 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 2045.76 lbf |
| Port thread 11 | Rc 3/8 (ISO-7-1) |
| Push-rod length | 2.28 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 58.45 lbf |
| Stroke | 2.24 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.88 in |
| Type | 24/24 |
| Type of operation | Cam |
| Version | Without boot |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875285939 |
| Size (mm x mm x mm) | 200 x 200 x 400 |
| UPC | 193133357032 |
| Weight (kg) | 8.158 |
| Weight (lb) | 17.985 |
| Thread length | 2.28 in |
| Brand | WABCO |
