Additional information
| Weight | 8,3 kg |
|---|---|
| Reference number | 2021710 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.0156 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 388.92 lbf |
| Output force 1 | 2686.47 lbf |
| Output force M | 2686.47 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.96 in |
| Type | 24/24 |
| Type of operation | Disc |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875283997 |
| Size (mm x mm x mm) | 209 x 191 x 301 |
| UPC | 193133355380 |
| Weight (kg) | 8.3 |
| Weight (lb) | 18.298 |
| Technical specification | OE specification |
| Brand | WABCO |
