Additional information
| Weight | 8,154 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 16.7529 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 1933.36 lbf |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 51.71 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/24 |
| Type of operation | Disc |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875283911 |
| Size (mm x mm x mm) | 226 x 226 x 328 |
| UPC | 193133355359 |
| Weight (kg) | 8.154 |
| Weight (lb) | 17.976 |
| Total lenght | 10.16 in |
| Brand | WABCO |
