Additional information
| Weight | 9,638 kg |
|---|---|
| Reference number | 22080445, 23238345 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.657 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 1888.40 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 89.92 psi |
| Return-spring force | 55.08 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/24 |
| Type of operation | Disc |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875282006 |
| Size (mm x mm x mm) | 373 x 212 x 198 |
| UPC | 193133353409 |
| Weight (kg) | 9.638 |
| Weight (lb) | 21.248 |
| Total lenght | 11.46 in |
| Brand | WABCO |
