Additional information
| Weight | 8,238 kg |
|---|---|
| Reference number | 1791421, 2021704, 1443314, 1686019, 1791421 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.9074 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 481 271 0 |
| Output force M | 2686.47 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Total lenght | 9.96 in |
| Type | 24/24 |
| Type of operation | Disc |
| GTIN | 04057875283492 |
| Size (mm x mm x mm) | 315 x 197 x 208 |
| UPC | 193133354918 |
| Weight (kg) | 8.238 |
| Weight (lb) | 18.162 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
