Additional information
| Weight | 9,469 kg |
|---|---|
| Reference number | 1686002, 1365122, 3530020A4A, A0204203018 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.9925 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 481 150 0 |
| Output force M | 2686.47 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 88.47 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Total lenght | 11.50 in |
| Type | 24/24 |
| Type of operation | Disc |
| GTIN | 04057875283232 |
| Size (mm x mm x mm) | 410 x 197 x 198 |
| UPC | 193133354758 |
| Weight (kg) | 9.469 |
| Weight (lb) | 20.876 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
