Additional information
| Weight | 7,567 kg |
|---|---|
| Reference number | 2192928 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 13.585 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 152.29 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 1461.26 lbf |
| Output force 1 | 1933.36 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port thread 12 | M12 x 1.5 JED – 152 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 79.77 psi |
| Return-spring force | 55.08 lbf |
| Stroke | 2.56 / 1.77 in |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.41 in |
| Type | 24/16 |
| Type of operation | Disc |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875281948 |
| Size (mm x mm x mm) | 325 x 220 x 190 |
| UPC | 193133353379 |
| Weight (kg) | 7.567 |
| Weight (lb) | 16.682 |
| Technical specification | OE specification |
| Brand | WABCO |
