Additional information
| Weight | 11,266 kg |
|---|---|
| Reference number | 5010260349, 1935448 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.30 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 22.6206 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 342 485 0 |
| Output force 3 | 2529.10 lbf |
| Output force M | 2529.10 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 3.39 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Total lenght | 11.18 in |
| Type | 30/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | welded: 895 801 770 4 |
| GTIN | 04057875281146 |
| Size (mm x mm x mm) | 472 x 225 x 213 |
| UPC | 193133352846 |
| Weight (kg) | 11.266 |
| Weight (lb) | 24.8372 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
