Additional information
| Weight | 8,2 kg |
|---|---|
| Reference number | 1685986, 1685985, 1426887, 1635888 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 0 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 123.28 psi |
| Opposite | 925 487 014 0 |
| Output force M | 2448.17 lbf |
| Port threads | M22 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Type | 22/24 IBV |
| GTIN | 04057875284932 |
| UPC | 193133356325 |
| Weight (kg) | 0 |
| Weight (lb) | 0 |
| Brand | WABCO |
