Additional information
| Weight | 9,2 kg |
|---|---|
| Reference number | 882224, 0882224, 7023704, WZ32480215F, 2089704, WA9253751000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.50 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 19.8778 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force 3 | 1573.66 lbf |
| Output force M | 1686.07 lbf |
| Port angle | 90° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Push-rod length | 8.39 in |
| Push-rod thread | M16 × 1.5 |
| Release pressure | 69.62 psi |
| Return-spring force | 29.23 lbf |
| Stroke | 2.95 / 2.95 in |
| Temperature range | -40°C to +80°C |
| Thread length | 8.39 in |
| Total lenght | 14.21 in |
| Type | 20/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without (M 16×1.5) |
| GTIN | 04057875278115 |
| Size (mm x mm x mm) | 473 x 205 x 205 |
| Weight (kg) | 9.2 |
| Weight (lb) | 20.283 |
| Technical specification | OE specification |
| Brand | WABCO |
