Additional information
| Weight | 10,199 kg |
|---|---|
| Reference number | A0234203818, A0234203718, 0234203718 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 24.4616 |
| Clevis pin | 0.55 in |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Nominal diameter | 8.5 mm |
| Output force | 321.48 lbf |
| Output force 1 | 1690.56 lbf |
| Output force 2 | 2234.60 lbf |
| Output force M | 2234.60 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 7.36 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.26 in |
| Type | 20/30 |
| Type of operation | Cam |
| Version | With boot |
| Wrench size | 0.94 in |
| Yoke | Yes |
| GTIN | 04057875285397 |
| Size (mm x mm x mm) | 555 x 205 x 215 |
| UPC | 193133356745 |
| Weight (kg) | 10.199 |
| Weight (lb) | 22.4849 |
| Return-spring force | 56.20 lbf |
| Brand | WABCO |
