Additional information
| Weight | 8,16 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 48.236 |
| Cooling | Air |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force | 1483.74 lbf |
| Port thread 11 | M16 x 1.5 |
| Push-rod length | 9.84 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 61.82 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 9.84 in |
| Type | 16/24 |
| Type of operation | Cam |
| Version | With boot |
| Wrench size | 0.94 in |
| Yoke | No |
| GTIN | 04057875287759 |
| Size (mm x mm x mm) | 592 x 388 x 210 |
| UPC | 193133359111 |
| Weight (kg) | 8.16 |
| Weight (lb) | 17.99 |
| Total lenght | 9.92 in |
| Brand | WABCO |
