Additional information
| Weight | 7 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.1605 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.96 in |
| Type | 16/16 |
| Type of operation | Disc |
| GTIN | 04057875284475 |
| UPC | 193133356011 |
| Weight (kg) | 7 |
| Weight (lb) | 15.432 |
| Size (mm x mm x mm) | 358 x 193 x 176 |
| Brand | WABCO |
