Additional information
| Weight | 10,82 kg |
|---|---|
| Reference number | 3276T1164 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 23.43 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 3293.45 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 7.56 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 84.12 psi |
| Return-spring force | 62.95 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.71 in |
| Type | 30/30 |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875408086 |
| Size (mm x mm x mm) | 485 x 230 x 210 |
| UPC | 193133414940 |
| Weight (kg) | 10.82 |
| Weight (lb) | 23.84 |
| Type of operation | Cam |
| Brand | WABCO |
