Additional information
| Weight | 8,882 kg |
|---|---|
| Reference number | 2530911 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.54 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 18 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 2675.23 lbf |
| Port thread 11 | M22 x 1.5 JED – 152 |
| Push-rod length | 2.76 in |
| Push-rod thread | M16 x 1.5 |
| Release pressure | 82.67 psi |
| Return-spring force | 58.45 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.75 in |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Screwed |
| GTIN | 04057875322702 |
| Size (mm x mm x mm) | 450 x 200 x 200 |
| UPC | 193133414735 |
| Weight (kg) | 8.882 |
| Weight (lb) | 19.58 |
| Type | 24/24 |
| Brand | WABCO |
