Additional information
| Weight | 8,885 kg |
|---|---|
| Reference number | 2530908 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 19.5091 |
| Clevis pin | 0.63 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 2675.23 lbf |
| Port thread 11 | M22 x 1.5 |
| Push-rod length | 2.76 in |
| Release pressure | 82.67 psi |
| Return-spring force | 58.45 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 10.83 in |
| Type | 20/24 |
| Version | With boot |
| Yoke | Screwed: 895 802 090 4 |
| GTIN | 04057875325857 |
| Size (mm x mm x mm) | 214 x 214 x 426 |
| UPC | 193133413653 |
| Weight (kg) | 8.885 |
| Weight (lb) | 19.588 |
| Type of operation | Cam |
| Brand | WABCO |
