Additional information
| Weight | 10,13 kg |
|---|---|
| Reference number | A 958 420 14 18, A9584201418 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.32 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 34.02 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 2270.57 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 2.36 in |
| Release pressure | 92.82 psi |
| Return-spring force | 58.45 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.42 in |
| Type | 20/24 HFL3 |
| Version | With boot |
| Yoke | Without |
| GTIN | 04057875285434 |
| Size (mm x mm x mm) | 580 x 255 x 230 |
| UPC | 193133414230 |
| Weight (kg) | 10.13 |
| Weight (lb) | 22.33 |
| Type of operation | Cam |
| Brand | WABCO |
