Additional information
| Weight | 7,9 kg |
|---|---|
| Reference number | A9584203718 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.32 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.0544 |
| Clevis pin | 0.55 in |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 1978.32 lbf |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Push-rod length | 2.36 in |
| Release pressure | 73.97 psi |
| Return-spring force | 61.82 lbf |
| Stroke | 2.24 / 2.24 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 9.92 in |
| Type | 16/24 |
| Version | With boot |
| GTIN | 04057875287551 |
| Size (mm x mm x mm) | 388 x 200 x 194 |
| UPC | 193133415060 |
| Weight (kg) | 7.9 |
| Weight (lb) | 17.416 |
| Type of operation | Cam |
| Brand | WABCO |
