Additional information
| Weight | 8,395 kg |
|---|---|
| Reference number | A0184205218, 1505448R, 1935459 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Bolt lengths | 1.67 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 13.76 |
| Clevis pins | Ball R8 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force m | n/a |
| Port thread 11 | M16 x 1.5 JED – 152 |
| ProVia warranty | 1 year |
| Push-rod length | 0.59 in |
| Release pressure | 73.97 psi |
| Return-spring force | n/a |
| Stroke | 2.24 / 2.24 in |
| Technical specification | AM specification |
| Temperature range | -40°F to +176°F |
| Total lenght | 10.08 in |
| Type of operation | Disc |
| GTIN | 04057877024499 |
| Size (mm x mm x mm) | 320 x 215 x 200 |
| UPC | 193134009619 |
| Weight (kg) | 8.395 |
| Weight (lb) | 18.51 |
| Type | 16/24 |
| Brand | WABCO |
