Additional information
| Weight | 9,455 kg |
|---|---|
| Reference number | 21115362, 21442206, 20535924, 2111536 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 17.351 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 145.04 psi |
| Output force M | 2585.30 lbf |
| Port thread 11 | M22 x 1.5 JED – 152 |
| Port thread 12 | M22 x 1.5 JED – 152 |
| Port threads | M22 x 1.5 |
| Push-rod length | 0.79 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 51.71 lbf |
| Stroke | 2.95 / 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 24/24 |
| Type of operation | Disc |
| GTIN | 04057875283508 |
| Size (mm x mm x mm) | 431 x 189 x 213 |
| UPC | 193133354635 |
| Weight (kg) | 9.455 |
| Weight (lb) | 20.845 |
| Total lenght | 11.81 in |
| Brand | WABCO |
