Additional information
| Weight | 0,68 kg |
|---|---|
| Reference number | 0000719744, 719744 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.428 |
| Charging pressure | 50.76 psi |
| Max. operating pressure | 290.1 psi |
| Opening pressure circuit 1+2 | 7.0 + 7.0 bar |
| Opening pressure circuit 3+4 | 7.0 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| GTIN | 04057875289760 |
| Size (mm x mm x mm) | 120 x 140 x 85 |
| Weight (kg) | 0.68 |
| Brand | WABCO |
