Additional information
| Weight | 0,671 kg |
|---|---|
| Reference number | 0014312606, 2089984 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.1915 |
| Charging pressure | 43.51 psi |
| Max. operating pressure | 290.1 psi |
| Opening pressure circuit 1+2 | 6.0 + 6.0 bar |
| Opening pressure circuit 3+4 | 5.5 bar |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +90°C |
| GTIN | 04057875289753 |
| Size (mm x mm x mm) | 114 x 134 x 78 |
| UPC | 193133361534 |
| Weight (kg) | 0.671 |
| Weight (lb) | 1.4793 |
| Brand | WABCO |
