Additional information
| Weight | 0,603 kg |
|---|---|
| Reference number | 1506448, 7069646, 7886, 6916, 164265, 2102006, S9630010510, 58124230, 5812423, 8283012000, 21151103260, 336490, 1133254, 4112002, 10102276, A05021210, 9630010510, 6300-9630010510, S9630010510, 07133000, 1319581, 10658, 49500466000, 495060, AIF0503, 1506448, S9630010510, 2090266, 052190, 8283012000, 1060742, 36006, 21151103260, WAB9630010510, 1013171 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Black/Red |
| Application | 971 002 |
| Calculated Volume (dm³) | 1.7205 |
| Comments | With non-return valve |
| Distance between holes | 3.39 in |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x Ø 8.5 mm – Flange |
| Port thread 1-1 | M16 x 1.5 |
| Port thread 1-2 | M16 x 1.5 |
| Port thread 2 | Ø 0.86 in |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port threads | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851086418 |
| Size (mm x mm x mm) | 178.5 x 94.5 x 102 |
| UPC | 193133449409 |
| Weight (kg) | 0.603 |
| Weight (lb) | 1.33 |
| Type | Release valve |
| Brand | WABCO |
