Additional information
| Weight | 0,165 kg |
|---|---|
| Reference number | 867882, 0867882, 010943, 205137, M059438, 5360-039, 9630060030, S44Y0E0010, S9630060030, 5810549, 5058105490, 1133256, 503200201, A05020219, S9630060030, 912032-00016, 1795010, 0859815, 49501101001, 0867882, S9630060030, 1912350, WA9630060030 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.2814 |
| Color | Knob – Red |
| Comments | with flange |
| Distance between holes | 1.46 in |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x Ø 8.5 mm |
| Nominal diameter | 6.0 mm |
| Port thread 1-2 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port threads | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Release valve |
| GTIN | 04057875298557 |
| Size (mm x mm x mm) | 88.5 x 79.5 x 40 |
| Weight (kg) | 0.165 |
| Weight (lb) | 0.364 |
| UPC | 193133449423 |
| Brand | WABCO |
