Additional information
| Weight | 1,796 kg |
|---|---|
| Reference number | 1519318, A0014310405, 72DB2K318AA, 61577722, 00000668, 04731117, 08790482, 82523016000, 99014360901, 0014310405, A0014310405, 82523016000, 307074, 99014360340, 22453340 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.4136 |
| Distance between bolts | 3.35×3.35 in |
| Exhaust | Flap |
| Max. operating pressure | 116.0 psi |
| Mounting | 2x M8 |
| Multi nominal diameter (from port 1 to x) | 10 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 41 | M22 x 1.5 |
| Port thread 42 | M22 x 1.5 |
| Port thread 43 | M22 x 1.5 |
| Port threads | M22 x 1.5 |
| Predominance | 8.70 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875302766 |
| UPC | 193133376279 |
| Weight (kg) | 1.796 |
| Weight (lb) | 3.9595 |
| Size (mm x mm x mm) | 158 x 134 x 114 |
| Brand | WABCO |
