Additional information
| Weight | 0,908 kg |
|---|---|
| Reference number | 4293832M1, 1506126, AL81937, S4700152150, 7700063841, 11047230, 60454740 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 0.897 |
| Comments | Circuit 2 |
| Delivered pressure | 290 psi |
| Distance between bolts | 1.89 in |
| Distance between holes | 1.97 in |
| Exhaust | Flap |
| Max. operating pressure | 101.53 / 725.19 psi |
| Medium | Mineral oil |
| Mounting | 2x Ø9.0 mm |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 41 | DIN 74235 – FL M10 x 1 |
| Port thread 42 | DIN 74235 – FL M10 x 1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | 2 Circuit |
| Size (mm x mm x mm) | 70 x 149 x 86 |
| UPC | 193133309819 |
| Weight (kg) | 0.908 |
| Weight (lb) | 2.002 |
| GTIN | 7895851073456 |
| Brand | WABCO |
