Additional information
| Weight | 2,366 kg |
|---|---|
| Reference number | CC452B200AA, 2T0607329B, 2T0607329B |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.443 |
| Distance between bolts | 3.35×3.35 in |
| Exhaust | Silencer |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x M10 with mounting plate |
| Multi Nominal diameter (From Port 1 to x) | 0.35 in |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 41 | M22 x 1.5 JED-388 |
| Port thread 42 | M22 x 1.5 JED-388 |
| Port thread 43 | M16 x 1.5 JED-388 |
| Predominance | 2.90 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851072411 |
| UPC | 193133377429 |
| Weight (kg) | 2.366 |
| Weight (lb) | 5.2161 |
| Size (mm x mm x mm) | 103 x 118 x 201 |
| Brand | WABCO |
