Additional information
| Weight | 2,158 kg |
|---|---|
| Reference number | 1529148, 20424431, 3173151 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.7434 |
| Distance between bolts | 3.35×3.35 in |
| Exhaust | Silencer |
| Max. operating pressure | 123.28 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.35 in |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 41 | M16 x 1.5 |
| Port thread 42 | M16 x 1.5 |
| Port thread 43 | M16 x 1.5 |
| Predominance | 1.45 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851032996 |
| UPC | 193133377030 |
| Weight (kg) | 2.158 |
| Weight (lb) | 4.7576 |
| Size (mm x mm x mm) | 191 x 141 x 139 |
| Brand | WABCO |
