Additional information
| Weight | 2,164 kg |
|---|---|
| Reference number | G931882020020, 6009005138008, 1504970, TDAS9730090100, S9730090100, 6300-9730090100, 0005661007, S9730090100, 1504970, S9730090100, 1350096, 20424432, 20252296, 252296, 20424432, 1350096, WAB9730090100 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.038 |
| Distance between bolts | 3.35×3.35 in |
| Exhaust | Silencer |
| Max. operating pressure | 123.28 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.35 in |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 41 | M16 x 1.5 |
| Port thread 42 | M16 x 1.5 |
| Port thread 43 | M16 x 1.5 |
| Predominance | 5.80 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851023567 |
| UPC | 193133450108 |
| Weight (kg) | 2.164 |
| Weight (lb) | 4.7708 |
| Size (mm x mm x mm) | 209 x 139 x 139 |
| Brand | WABCO |
