Additional information
| Weight | 2,23 kg |
|---|---|
| Reference number | 1518266, A0014318705, 04773981, 04773986, 42033548, 42051712, 42051714, 42065521, 42065522, 42100481, 0014318705, S9730025390, 322799, 502658208, 6300-9730025390, 0005661003, 81523016118, 81523016120, 81523016154, 81523016165, 81523016173, 0014318705, 0024310105, 0034310205, A0014318705, 42100481, S9730025390, S9730025390, 99100360007, WAB9730025390 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 3.6132 |
| Distance between bolts | 3.35×3.35 in |
| Exhaust | Flap |
| Max. operating pressure | 116.0 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.31 / 0.08 in |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 41 | M16 x 1.5 |
| Port thread 42 | M16 x 1.5 |
| Port thread 43 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Predominance | 4.35 psi |
| Switch pressure | 36.26 psi |
| Technical specification | OE specification |
| GTIN | 04057875303343 |
| Size (mm x mm x mm) | 164 x 136 x 162 |
| UPC | 193133450092 |
| Weight (kg) | 2.23 |
| Weight (lb) | 4.9163 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
